2023
Yamaha
Raptor 700
Stock #YA16576
MSRP: $9,399 USD
‹
›
Reset Zoom
X
‹
›
-
+
‹
›
This vehicle is getting attention.
170 people have recently viewed it.
Check Availability
Hi, my name is
First Name
Last Name
and I'm interested in this
2023 Yamaha Raptor 700
. I'm in the
Zip Code
area and you can reach me at
Email
or on my
Mobile
Home
Work
phone at
Phone
.
What is your preferred method of contact?
Email
Phone
Text
Is this unit available?
What payment terms are available?
When can I test ride this unit?
Questions/Comments
VehicleId
SubscriptionId
SubscriberId
Year
ModelName
MakeDivision
ProductTypeId
StyleName
ReturnURL
ModelNumber
Check Availability
Details
Status:
New
Vehicle:
2023 Yamaha Raptor 700
VIN:
5Y4AML6EXPA101328
Color:
Yamaha Black
Stock Number:
YA16576
Title:
Clear
Location:
Edwards Motorsports & RVs
Warranty:
Manufacturer's w/ Extended Available
Specifications
BRAKES
Front Brake Type:
Dual Hydraulic Disc
Rear Brake Type:
Hydraulic Disc
DRIVE LINE
Driveline Type:
4X2
Number Of Driveline Modes:
1
Rear Solid Axle:
Yes
ENGINE
Bore (in):
4.02
Bore (mm):
102
Carburetion Type:
Fuel Injected
Compression Ratio:
10.0
Cooling:
Liquid
Cylinders:
1
Displacement (cc):
686
Displacement (ci):
41.9
Engine Stroke:
4-Stroke
Engine Type:
Single-Cylinder
Fuel Injector Size (mm):
44
Fuel Injector:
Yes
Fuel Requirements:
Regular
Fuel Type:
Gas
Starter:
Electric
Stroke (in):
3.31
Stroke (mm):
84
Valve Configuration:
SOHC
Valves Per Cylinder:
4
Valves:
4
EXTERIOR
Bash Plate (Front):
Yes
Body Material:
Plastic
Floor Board Location:
Driver
Foot Peg Location:
Driver
Frame:
Aluminum / Steel
INSTRUMENTATION
Fuel Level Warning Type:
Light
Temperature Warning Type:
Light
LIGHTS
Type:
LED
SEATS
Number Of Seats:
1
Seat Height (in):
32.7
Seat Height (mm):
830.6
Seat Location:
Driver
Seat Material:
Vinyl
Seat Type:
One-Piece
STEERING
Steering Control:
Handlebar
Steering Type:
Manual
SUSPENSION
Front Adjustable Fork Pre-Load:
Yes
Front Suspension Type:
Independent Double Wishbone
Front Travel (in):
9.1
Front Travel (mm):
231.1
Number Rear Shock Absorbers:
1
Rear Adjustable Shock / Spring Pre-Load:
Yes
Rear Suspension Material:
Aluminum
Rear Suspension Type:
Swing Arm
Rear Travel (in):
10.1
Rear Travel (mm):
256.5
TECHNICAL SPECIFICATIONS
Engine Displacement to Weight (cc):
1.63
Fuel Capacity (gal):
2.9
Fuel Capacity (l):
11
Ground Clearance (in):
9.4
Ground Clearance (mm):
238.8
Height (in):
43.9
Height (mm):
1115.1
Length (ft):
6.05
Length (ft/ft):
6
Length (ft/in):
0.6
Length (in):
72.6
Length (mm):
1844
Wet Weight (kg):
191.4
Wet Weight (lbs):
422
Wheelbase (in):
50.4
Wheelbase (mm):
1280.2
Width (in):
45.5
Width (mm):
1155.7
TRANSMISSION
Number Of Speeds:
5
Primary Drive (Rear Wheel):
Chain
Reverse:
Yes
Transmission Type:
Manual
WHEELS & TIRES
Front Tire (Full Spec):
Maxxis® AT 22 X 7-10
Front Tire Diameter (in):
22
Front Tire Width:
7
Front Wheel Diameter:
10
Rear Tire (Full Spec):
Maxxis® AT 20 X 10-9
Rear Tire Diameter (in):
20
Rear Tire Width:
10
Rear Wheel Diameter:
9
Tire Brand:
Maxxis®
Tube / Tubeless:
Tubeless
Wheels Composition:
Aluminum
