2020 Yamaha Grizzly EPS

Stock #YA16220A
Your Price: $8,150
Check Availability Hi, my name is and I'm interested in this 2020 Yamaha Grizzly EPS . I'm in the area and you can reach me at or on my phone at .

TRAIL TESTED, RIDER APPROVED

The best-performing ATV in its class, with superior capability, all-day comfort, and legendary durability.

TOP FEATURES

  • Big Bore Engine Designed For Aggressive Trail Riding
    The Grizzly® EPS brings even Yamaha’s renowned riding excitement without losing an ounce of comfort, thanks to its potent 700-class engine designed for smooth running and enhanced midrange power.
  • High-Performance Ultramatic® Transmission
    Yamaha’s class-leading transmission combines immediate response with advanced features like natural, all-wheel engine braking for control on confidence. And the Ultramatic proves itself time and time again to be the most durable ATV transmission on the market.
  • Trail-Ready Chassis
    With plenty of ground clearance and adjustable suspension, the Grizzly EPS tackles rough terrain with ease. The long-travel shocks, wide-arc A-arms and full-body skid plates ensure the Grizzly EPS is ready to keep going when you are.
  • Yamaha’s Exclusive On-Command® 4WD
    Unlike so many computer-controlled 4WD systems on the market, the Yamaha On-Command system keeps the rider in charge, with selectable 2WD, 4WD limited-slip, and 4WD with diff. lock modes to ensure the Grizzly EPS delivers power predictably and consistently.
  • Class-Leading Power Steering
    Reduced fatigue, excellent control and trail feel all come standard with Grizzly’s best-in-industry speed-sensitive Electric Power Steering (EPS).
  • Status:
    Pre-Owned
  • Vehicle:
    2020 Yamaha Grizzly EPS
  • VIN:
    5Y4AMK338LA101089
  • Mileage:
    2,939 miles
  • Stock Number:
    YA16220A
  • Title:
    Clear
  • Location:
    Edwards Motorsports & RVs
  • Warranty:
    As Is

BRAKES

  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Dual Hydraulic Disc

DRIVE LINE

  • Differential Lock Location:
    Front
  • Driveline Brand:
    On-Command™
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Limited Slip Differential Location:
    Front
  • Number Of Driveline Modes:
    2

ENGINE

  • Bore (in):
    4.02
  • Bore (mm):
    102
  • Carburetion Brand:
    Mikuni
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    10.0
  • Cooling:
    Liquid
  • Cylinders:
    1
  • Displacement (cc):
    686
  • Displacement (ci):
    41.8
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    Single-Cylinder
  • Fuel Injector Size (mm):
    44
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Starter:
    Electric
  • Stroke (in):
    3.31
  • Stroke (mm):
    84
  • Valve Configuration:
    SOHC
  • Valves Per Cylinder:
    4
  • Valves:
    4

EXTERIOR

  • Bash Plate (Front):
    Yes
  • Bash Plate (Rear):
    Yes
  • Body Material:
    Plastic
  • Brush Guard:
    Yes
  • CV Boot Cover:
    Yes
  • Floor Board Location:
    Driver
  • Foot Peg Location:
    Driver
  • Frame:
    Steel
  • Full Length Skid Plate:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    LED

SEATS

  • Number Of Seats:
    1
  • Seat Height (in):
    36.1
  • Seat Height (mm):
    916.9
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Type:
    One-Piece

STEERING

  • Steering Brand:
    Electronic Power Steering (EPS)
  • Steering Control:
    Handlebar
  • Steering Type:
    Power

STORAGE

  • Capacity (kgs):
    49.9
  • Capacity (kgs):
    89.8
  • Capacity (lbs):
    110
  • Capacity (lbs):
    198
  • Fender Storage Location:
    Front

SUSPENSION

  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Suspension Type:
    Independent Double Wishbone
  • Front Travel (in):
    7.6
  • Front Travel (mm):
    193
  • Number Rear Shock Absorbers:
    2
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Stabilizer Bar:
    Yes
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Independent Double Wishbone
  • Rear Travel (in):
    9.1
  • Rear Travel (mm):
    231.1

TECHNICAL SPECIFICATIONS

  • Engine Displacement to Weight (cc):
    0.98
  • Fuel Capacity (gal):
    4.8
  • Fuel Capacity (l):
    18.2
  • Ground Clearance (in):
    11.3
  • Ground Clearance (mm):
    287
  • Height (in):
    49.3
  • Height (mm):
    1252.2
  • Length (ft):
    6.79
  • Length (ft/ft):
    6
  • Length (ft/in):
    9.5
  • Length (in):
    81.5
  • Length (mm):
    2070.1
  • Towing Capacity (kgs):
    599.7
  • Towing Capacity (lbs):
    1322
  • Turning Radius (ft):
    12.2
  • Wet Weight (kg):
    318
  • Wet Weight (lbs):
    701
  • Wheelbase (in):
    49.2
  • Wheelbase (mm):
    1249.7
  • Width (in):
    48.4
  • Width (mm):
    1229.4

TRANSMISSION

  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Transmission Brand:
    UltraMatic™
  • Transmission Type:
    Continuously Variable (CVT)

WHEELS & TIRES

  • Front Tire (Full Spec):
    Maxxis® AT26 x 8 - 12 MU05Y
  • Front Tire Diameter (in):
    26
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire (Full Spec):
    Maxxis® AT26 x 10 - 12 MU06Y
  • Rear Tire Diameter (in):
    26
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    12
  • Tire Brand:
    Maxxis®
  • Tube / Tubeless:
    Tubeless
  • Wheels Composition:
    Aluminum
